Open Timber Decking for Pallet Racking - Heavy Duty Storage Solution
Questions about this unit? Talk to us
Your selection, drawn to scale
Check it fits before you order
The drawing changes with every option you pick, so you can hold it up against your wall, ceiling and doorways.
Key Features of Open Timber Decking
- Open timber decking allows you to store undersized pallets on your pallet racking.
- Enables storage of items that are not palletised.
- Sawn open boarded kiln dried timber decks.
- Supplied in 1 or 2 sections (2225w and above is 2 sections).
- 32mm thickness for heavy-duty use.
- The open spacing on the timber decks means there is more airflow around stored items.
Load Capacities Per Deck (UDL)
- 1150w x 900d - 1600kg
- 1150w x 1100d - 1200kg
- 1350w x 900d - 1800kg
- 1350w x 1100d - 1500kg
- 1825w x 900d - 2250kg
- 1825w x 1100d - 1800kg
- 2225w x 900d - 3200kg
- 2225w x 1100d - 2400kg
- 2700w x 900d - 3600kg
- 2700w x 1100d - 3000kg
- 3300w x 900d - 4000kg
- 3300w x 1100d - 3500kg
Technical Specifications
| Specification | Measurement |
|---|---|
| Thickness | 32mm |
FAQ
Can I use these decks for non-palletized items?
Yes, the open timber decking is designed for storing both undersized pallets and non-palletized items.
What is the maximum load capacity?
The maximum load capacity varies by size, with options available up to 1,200kg, 1,500kg, 1,600kg, 1,800kg, 2,250kg, 2,400kg, 3,000kg, 3,200kg, 3,500kg, 3,600kg or 4,000kg (as selected above).
How are the timber decks supplied?
The timber decking is supplied in one or two sections based on the width.
