Premium Heavy Duty Longspan Shelving - 2000mm High - Blue & Orange
Questions about this unit? Talk to us
Your selection, drawn to scale
Check it fits before you order
The drawing changes with every option you pick, so you can hold it up against your wall, ceiling and doorways.
Key Features of Premium Longspan Shelving
- Heavy Duty Longspan shelving bay 2000mm high
- Industrial grade steel, ideal for storing heavy-duty, bulky loads
- Tested to FEM standards
- 2x frame uprights delivered fully assembled
- Blue uprights with powder-coated finish
- Levels are adjustable in height every 50mm
- 2x safety locking pins per beam for extra security
- Powder-coated orange finish on the beams
- 3x chipboard decks, 22mm thickness
- Up to 300kg, 320kg, 440kg, 500kg, 550kg, 590kg, 610kg, 670kg, 810kg or 850kg (as selected above) load capacities per level for heavy-duty storage
- Ground level can be used for pallet storage - no bottom beams required
- Floor fixings and steel leveling plates are provided
- Boltless assembly (except when fixing to the floor)
- Longspan shelving support beams are available for extra reinforcement
- Extension bays available to maximize storage space
UDL (Uniformly Distributed Load) - The load capacities stated are the maximum weights each level can hold. This weight needs to be evenly distributed across each level.
Premium Longspan Shelving is one of our most robust shelving units. Perfect for use in an industrial or warehouse environment, these units can be used for a wide range of storage due to their large load capacity. It is constructed using high-quality, thick upright frames and beams, and once assembled, these shelving units are impressively sturdy and reliable. Multiple sizes are available for your storage requirements, choose from up to 2700mm wide units, great for bulkier storage.
Ideal Uses:
- Industrial Environment
- Warehouses
- Heavy Duty Storage
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Frame Height | 2000mm |
| Depth | 600mm or 900mm (as selected above) |
| Beam Width | 1000mm, 1200mm, 1400mm, 1825mm, 1900mm, 2300mm or 2700mm (as selected above) |
| External Bay Width (overall, outside of uprights) | 1100mm, 1300mm, 1500mm, 1925mm, 2000mm, 2400mm or 2800mm (as selected above; beam width + 100mm for the two 50mm upright frames) |
| Clear Entry per Bay (usable opening) | 990mm, 1190mm, 1390mm, 1815mm, 1890mm, 2290mm or 2690mm (as selected above; beam width − 10mm) |
| Load Capacity per Level | 300kg, 320kg, 440kg, 500kg, 550kg, 590kg, 610kg, 670kg, 810kg or 850kg UDL per shelf (as selected above) |
| Chipboard Deck Thickness | 22mm |
Technical Specifications
- Material: Industrial grade steel
- Finish: Powder-coated
- Assembly: Boltless (except for floor fixing)
FAQ
What is the maximum load capacity?
The maximum load capacity is up to 850kg per level, depending on the width and depth of the bay.
Is assembly required?
Yes, the shelving requires assembly; however, it features a boltless design for easy setup.
Can I expand my shelving unit?
Yes, extension bays are available to increase your storage capacity.
