Heavy Duty 5x Industrial Shelving - 1980mm High - 340kg Capacity - Steel Construction - Pack of 5
Questions about this unit? Talk to us
Your selection, drawn to scale
Check it fits before you order
The drawing changes with every option you pick, so you can hold it up against your wall, ceiling and doorways.
Key Features of Heavy Duty Steel Shelving
- Available in 4, 5, and 6 level units to suit your needs
- Constructed from 2mm thick powder coated European steel
- Strong galvanised steel shelves, tested to hold 340kg (915mm wide) or 200kg (1220mm wide) UDL per shelf
- Total load capacity of 800–2,040kg UDL per unit
- Single piece uprights for enhanced stability
- Additional shelves can be purchased as needed
- Steel support beams on each level for extra reinforcement
- Boltless 'stud & keyhole' design for easy assembly
- Includes 4/5/6 steel decks standard with each unit
- Manufactured to ISO standards for quality assurance
- Ideal for use in commercial and industrial environments
- Low profile shelf beam design maximises storage efficiency
- Quick & easy assembly with an included rubber mallet
- Full range of accessories available, such as joining tie plates
- Adjustable shelf height every 3.8cm (1.5 inches)
- Accessible from both sides, no cross bracing needed
- Free rubber assembly mallet included
Ideal Uses
- Regular picking operations
- Archive and document storage
- Small parts storage
- Heavy boxes and containers
- Domestic item storage
Product Overview
The Heavy Duty steel shelving range is designed as a reliable workhorse for frequent use in industrial, commercial, and retail environments. This shelving has a proven track record of use in warehouses and stockrooms for over 25 years, utilizing a tested boltless design.
This modular shelving system has been rigorously tested to meet FEM (European Federation of Material Handling) standards, making it suitable for daily industrial use.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Height | 1980mm |
| Load Capacity per Shelf | 340kg (915mm wide) or 200kg (1220mm wide) UDL |
| Total Load Capacity | 800–2,040kg UDL (load per shelf × number of levels, depends on the size selected) |
Technical Specifications
- Material: 2mm thick powder coated European steel
- Design: Boltless 'stud & keyhole'
- Adjustable shelf height: Every 3.8cm (1.5 inches)
Frequently Asked Questions
What is the maximum load capacity?
The maximum load capacity is 340kg (915mm wide) or 200kg (1220mm wide) per shelf and up to 800–2,040kg total per unit.
Can I adjust the height of the shelves?
Yes, the shelves can be adjusted every 3.8cm (1.5 inches) to accommodate various storage needs.
Is assembly required?
Yes, assembly is required, but it is quick and easy with the included rubber mallet.
